Bio Waste Incinerator


Basic Info.

Pullution Sources:Solid Waste Processing
Processing Methods:Combustion
Export Markets:Global

Additional Info.

Trademark:clover

Product Description

Incinerator is a incineration gear, direct fire waste by gas fuel or oi gas. As distinct circumscription, incinerator could be termed many words as under:

Treatment capacity: Small scale incinerator, large scale incinerator and incineration pant.

Waste substance: Municipal waste incinerator, medical waste incinerator, animal cremation incinerator, individual cremators

Incinerator gas: Gas incinerator, petroleum incinerator

Waste to Energy (WTE): WTE incinerator, non-WTE incinerator

Incinerator Manufacturer: China incinerator producer, UK incinerator producer, USA incinerator producer, India incinerator manufacturer.

Famous Incinerator manufacturer firm: Inciner8(UK), Clover Incinerator(China), Pennram (USA), Haat (India)

Burning Speed: 5kgs/hour, 10 kgs/hour, 15 kgs/hour, 20 kgs/hour, 30 kgs/hour, 50 kgs/hour, 100 kgs/hour, 150 kgs/hour, 300 kgs/hour, 500 kgs/hour

Nous fournissons des capacité S de 10/15/20/50/100/150/300/500 Kg / Equipements heures. Chaque anné E, nous vendons plus de 50 unité S d'é Quipements d'outre-mer. L'é Quipement est de petite taille, rendement é Levé, processus raisonnable, des technologies medical incineratoe, medical incinerator 10kg cost, medical incinerator 15kg/hr, medical incinerator audit, medical incinerator burner, medical incinerator buyer, de pointe et de haut degré Sans hazard. Il est IDé Al pour les é Quipements de traitement des ordures hô Pital, laboratoire, hô Tel, gare, etc Le brû Leur de combustion, d'origine de l'Italie et le Japon cé Lè Bre marque ou techniques. Mise à Jour la conception du modè Le que PAR 3T (tempé Rature, temps, Turbulence).

Items/Model TS10(PLC) TS20(PLC) TS30(PLC) TS50(PLC) TS100(PLC)
Burn Rate 10 kg/hour 20 kg/hour 30 kg/hour 50 kg/hour 100 kg/hour
Feed Capacity 20kg 40kg 60kg 100kg 200 kg
Control Mode PLC PLC PLC PLC PLC
Combustion Chamber 100L 210L 330L 560L 1200L
Internal Dimensions 50x50x40cm 65x65x50cm 75x75x60cm 100x80x70cm 120x100x100cm
Secondary Chamber 50L 110L 180L 280L 600L
Smoke Filter Chamber Yes Yes Yes Yes Yes
Feed Mode Manual Manual Manual Manual Manual
Voltage 220V 220V 220V 220V 220V
Power 0.5Kw 0.5Kw 0.5Kw 0.7Kw 0.7Kw
Oil Consumption (kg/hour) 5.4–12.6 7.8–16.3 10.2–20 12.1–24 14–28
Gas Consumption (m3/hour) 6.2–11.4 8–15.7 9.8–20 9.9–26.1 10–32.2
Temperature Monitor Yes Yes Yes Yes Yes
Temperature Protection Yes Yes Yes Yes Yes
Oil Tank 100L 100L 100L 100L 200L
Feed Door 30x30cm 45x40cm 55x50cm 70x55cm 80x60cm
Chimney 3Meter 3Meter 5Meter 5Meter 10Meter
Chimney Type Stainless Steel Stainless Steel Stainless Steel Stainless Steel Stainless Steel
Residency Time 2.0 Sec. 2.0 Sec. 2.0 Sec. 2.0 Sec. 2.0 Sec.
Gross Weight 1500kg 2200kg 3000kg 4500kg 6000kg
External Dimensions 140x90x120cm 160x110x130cm 175x120x140cm 230x130x155cm 260x150x180cm
